Description
56 output traffic controller (48-way motor vehicle light signal output, and 8-way pedestrian light signal output)
Features:
(1) The signal machine supports weekday schemes, weekend schemes, and special dayschemes.
(2)A maximum of 24 plans and 24 time periods can be set.A maximum of 30 special days can be set.
(3)Support 2-way pedestrian button input
(4) Single-point multi-period fixed-cycle control, single-point adaptive control, green wave control, secret service control.
(5) Panel manual control, remote control, background remote control.
(6) Support fault detect: signal output detection, green conflict detection, communication fault detection.
(7)GPS
Performance
(1) 56 output (48-way motor vehicle light signal output, and 8-way pedestrian light signal output)
(2) Working voltage:220(±20%)VAC,5O±2HZ ; Input AC Power Consumption≤10W(traffic light not included)
(3) Working temperature:-40℃—+70℃
(4) Environment relative humidity:45%-95%
(5) The output driver :≥600W/DAY
(6)Each way is equipped with independent insurance
(7)Anti-thunder measures and filtering measures
(8) Size: 560mm*370mm*1080mm
