Matrix Radar Speed Sign

Matrix radar speed sign utilizes clean solar energy, is suitable for speed limit reminders, and features ease of use and simple installation. With an optimized power management solution, this product can avoid charging under sufficient sunlight and still work continuously for more than a week during rainy weather.

Get A Free Quote Now

Description

For privacy reasons YouTube needs your permission to be loaded.

Matrix Radar Speed Sign delivers accurate real-time vehicle speed visualization and active traffic warning functions. First of all, as a practical and reliable solution for modern road safety management, it is widely deployed in residential areas, school zones, rural roads and various traffic monitoring scenarios. In this way, it can effectively standardize driving speed and greatly reduce speeding-related accidents.

Core Product Features

To start with, the Matrix Radar Speed Sign adopts imported high-precision traffic radar, delivering stable and reliable performance for long-term outdoor operation.
Furthermore, it supports adjustable radar sensitivity according to road and traffic conditions, ensuring accurate detection in diverse traffic scenarios.
Besides, it enables multi-task detection and stable operation on complex roads, perfectly satisfying diverse traffic supervision demands.
In addition, it is compatible with AC, DC and solar power supplies, supporting flexible deployment for wired and off-grid road sites.
Meanwhile, it is equipped with a full-screen LED dot matrix to display speed, text and images synchronously for intuitive driver reminders.
Moreover, it comes with an external flash unit to significantly enhance speed warning and reminder effects.
Apart from that, the Matrix Radar Speed Sign supports horizontal and vertical installation with 2-digit or 3-digit display options to adapt to various scenarios.
What’s more, it has a built-in photosensitive sensor for real-time automatic brightness adjustment, ensuring clear day and night visibility and energy conservation.
In addition to the above functions, it provides static and flashing display modes for flexible use and optimized warning effects.
Meanwhile, it integrates a built-in liquid crystal navigation controller with simple operation and rich expandable functions.
Finally, the Matrix Radar Speed Sign supports wireless remote setting, simplifying daily operation and parameter adjustment greatly.

Matrix Radar Speed Sign Technical Parameters

Frame Size:1080x780x130mm
LED Display Size:800x640mm
LED resolution: 40*32 pixels
LED Display Color: Red / Green/Amber
Speed Detection Range: 10–199 KM/H
Detection Accuracy: ±1 KM/H (MPH optional)
Radar Frequency: 24.125 GHz (K-band)
Speed Unit: KMH / MPH switchable
Detection Distance: Up to 300 meters for trucks, 200 meters for trolleys
Visible Distance: 300 meters
Operating Temperature: -20℃ to 70℃
Power Supply Specification: DC / AC / Solar power (60W 30A solar system support)

Customization Options

- Wireless remote control function
- Wireless data download system
- Custom solar panels and battery configurations
- Matching trailer device for mobile deployment
